QHY600M/C PH Photographic Camera (Short BFL)

QHY600M/C PH Photographic Camera (Short BFL)

Starting Price: $4,499.00 Sale Price: $3,909.00 Price as Configured: $3,909.00
Brand: QHYCCD / SKU: QHY-600M/C-PH-SBFL
The QHY600 (with short back focal length) is the premier astrophotography camera. It has a massive Sony IMX 455 back-lit sensor for advanced imaging applications with low read noise and 16-bit output. It also offers a full frame (35 mm) format with 3.76-micron pixels and a 36 mm x 24 mm sensor to bring out the best in your imaging data. QHY offers both monochrome and color versions.
Version (Required)
Recommended Add-ons and Accessories
Product Price Quantity
QHY-020112 - QHY M54 All-In-One-Kit
QHY-020112 - QHY M54 All-In-One-Kit
About This Product
  • Compatible with all cooled CMOS cameras, QHY CFW3-S-SR, CFW3-S-US, CFW3-L, and OAG-M.
  • Kit includes:
    • 1x 5mm M54 to M48 Adapter
    • 1x 3mm M54 to M42 Adapter
    • 1x QHY 2,5mm 2" Filter Fixer #1932780
    • 1x 4mm M54 Screwed Adapter (original name QHY #020070)
    • 1x Cam Top Adapter (QHY #020063)
    • 1x 0.5mm/1mm/2mm/3mm/7mm/10mm/14mm Spacer
    • 8x 8mm M3 screws
    • 8x 10mm M3 screws
    • 8x 12mm M3 screws
    • 8x 14mm M3 screws
    • 8x 16mm M3 screws
    • 8x 21mm M3 screws
    • 8x 24mm M3 screws
    • 8x 28mm M3 screws
    • 8x 36mm M3 screws
    • 8x 50mm M3 screws
$135.00 each
View More Add-ons and Accessories

Recommended Add-ons and Accessories

Enter the quantity desired for each item and click the close button to continue with your purchase.
QHY-020112 - QHY M54 All-In-One-Kit
QHY-020112 - QHY M54 All-In-One-Kit
$135.00
Qty:
View Details
« Back to All Add-ons
QHY-020112 - QHY M54 All-In-One-Kit
About This Product
  • Compatible with all cooled CMOS cameras, QHY CFW3-S-SR, CFW3-S-US, CFW3-L, and OAG-M.
  • Kit includes:
    • 1x 5mm M54 to M48 Adapter
    • 1x 3mm M54 to M42 Adapter
    • 1x QHY 2,5mm 2" Filter Fixer #1932780
    • 1x 4mm M54 Screwed Adapter (original name QHY #020070)
    • 1x Cam Top Adapter (QHY #020063)
    • 1x 0.5mm/1mm/2mm/3mm/7mm/10mm/14mm Spacer
    • 8x 8mm M3 screws
    • 8x 10mm M3 screws
    • 8x 12mm M3 screws
    • 8x 14mm M3 screws
    • 8x 16mm M3 screws
    • 8x 21mm M3 screws
    • 8x 24mm M3 screws
    • 8x 28mm M3 screws
    • 8x 36mm M3 screws
    • 8x 50mm M3 screws
QHY-020104 - QHY 10mm M54 Adapter for Canon EF Lens
QHY-020104 - QHY 10mm M54 Adapter for Canon EF Lens
$35.00
Qty:
View Details
« Back to All Add-ons
QHY-020104 - QHY 10mm M54 Adapter for Canon EF Lens
About This Product
  • Formerly known as Combo kit B1, this will connect QHY268M or QHY600M (Short BFL Version) with Canon EF lenses that require 44.1mm to camera with filter wheel
  • Product No.: 020104
  • Compatible with: QHY268M/600M (short BFL version) and CFW3L (large filter wheel to Connect: Canon EF Lens
Kit Includes:
  • 10mm M54 Canon EF Adapter - 1
Notes:
  • This part was previously known as # 020071
QHY-020105 - QHY 12.5mm M54 Adapter for Nikon F Lens with 0.5mm Spacer
QHY-020105 - QHY 12.5mm M54 Adapter for Nikon F Lens with 0.5mm Spacer
$40.00
Qty:
View Details
« Back to All Add-ons
QHY-020105 - QHY 12.5mm M54 Adapter for Nikon F Lens with 0.5mm Spacer
About This Product
Also known as Combo B3, this connects QHY268M or QHY600M (Short BFL Version) cameras with Nikon F lenses that require 46.5mm to camera with filter wheel.
  • Product No.: 020105
  • Compatible with:QHY268M/600M (short BFL version) and CFW3L (large filter wheel)
  • To Connect: Nikon F Lens
Kit Includes:
  • 12mm M54 Nikon F Adapter - 1
  • 0.5mm Spacer - 1
QHY-020123 - QHY 600SBFL-CFW3XL Adapter
QHY-020123 - QHY 600SBFL-CFW3XL Adapter
$20.00
Qty:
View Details
« Back to All Add-ons
QHY-020123 - QHY 600SBFL-CFW3XL Adapter
About This Product
This adapter is designed for connecting the QHY600M SBFL and QHY CFW3XL. There are also three 6mm M3 screws and three 8mm M3 screws provided. The adapter can also connect CFW3L and OAGL.
QHY-CFW3-XL (110048) - QHY Color Filter Wheel - Extra Large
QHY-CFW3-XL (110048) - QHY Color Filter Wheel - Extra Large
$519.00
Qty:
View Details
« Back to All Add-ons
QHY-CFW3-XL (110048) - QHY Color Filter Wheel - Extra Large
About This Product
The QHY CFW3 series filter wheels are available in four sizes to accommodate filters from 1.25-inch to 50 millimeters square. Now, all CFW3-XL filter carousels are updated with M48 threads and will support mounted 2-inch screw-in filters as well as 50mm round unmounted filters.

This product is the Extra Large (XL) size.

Model Filter Supported
CFW3XL Slot 1: 9 position 2inch mounted/ 50mm unmounted & 50mm square
Slot 2: 7 position 50mm*50mm square
CFW3L 7 position 2inch mounted/50mm unmounted
CFW3M-SR 5 position 2inch mounted/50mm unmounted
CFW3M-US 7 position 36mm unmounted
CFW3S-SR 7 position 1.25inch mounted/31mm unmounted
CFW3S-US 7 position 1.25inch mounted/31mm unmounted

QHY-030029 - QHY Active Extension Cable, DC 5V, 10m Long
QHY-030029 - QHY Active Extension Cable, DC 5V, 10m Long
$60.00
Qty:
View Details
« Back to All Add-ons
QHY-030029 - QHY Active Extension Cable, DC 5V, 10m Long
About This Product
Why do you need an Active Extension Cable?

According to the characteristics of USB3.0, the maximum supported cable length of USB3.0 is about 3 meters, or the transmission stability cannot be guaranteed above 3 meters. In order to ensure the image quality, the standard USB cable length of QHY is 1.8 meters.
QHY-030028 - QHY Active Extension Cable, DC 5V, 5m Long
QHY-030028 - QHY Active Extension Cable, DC 5V, 5m Long
$50.00
Qty:
View Details
« Back to All Add-ons
QHY-030028 - QHY Active Extension Cable, DC 5V, 5m Long
About This Product
Why do you need an Active Extension Cable?

According to the characteristics of USB3.0, the maximum supported cable length of USB3.0 is about 3 meters, or the transmission stability cannot be guaranteed above 3 meters. In order to ensure the image quality, the standard USB cable length of QHY is 1.8 meters.
QHY-CFW3-L (110047) - QHY Color Filter Wheel - Large
QHY-CFW3-L (110047) - QHY Color Filter Wheel - Large
$279.00
Qty:
View Details
« Back to All Add-ons
QHY-CFW3-L (110047) - QHY Color Filter Wheel - Large
About This Product
The QHY CFW3 series filter wheels are available in four sizes to accommodate filters from 1.25-inch to 50 millimeters square.

This product is the Large size.

Model Filter Supported
CFW3XL Slot 1: 9 position 2inch mounted/ 50mm unmounted & 50mm square
Slot 2: 7 position 50mm*50mm square
CFW3L 7 position 2inch mounted/50mm unmounted
CFW3M-SR 5 position 2inch mounted/50mm unmounted
CFW3M-US 7 position 36mm unmounted
CFW3S-SR 7 position 1.25inch mounted/31mm unmounted
CFW3S-US 7 position 1.25inch mounted/31mm unmounted

QHY-OAG-M (100074) - QHY Off-Axis Guider - Medium
QHY-OAG-M (100074) - QHY Off-Axis Guider - Medium
$149.00
Qty:
View Details
« Back to All Add-ons
QHY-OAG-M (100074) - QHY Off-Axis Guider - Medium
About This Product
The QHY Off-Axis Guider (OAG) has three models (QHYOAG-S,QHYOAG-M,QHYOAG-L).

This product is the Medium version.

Model QHYOAG-S QHYOAG-M QHYQAG-L
Telescope Interface M42/0.75 M54/0.75 M62/0.75
Diameter of 6 x M3 screw hole positions 54mm 62mm 68mm
Suitable for CCD/CMOS Size 1inch or smaller 4/3 inch

APS-C,

APS-H,

36 x 24mm

QTY:
Price as Configured: $3,909.00

Product Help
Need help deciding?
Tell us what you're looking for, and we’ll point you in the right direction. .



The curve shows absolute QE
