Officina Stellare RiDK 600 F/7

About This Product

The Officina Stellare 3" Off-Axis Guider is thin and solid for great performance with today’s larger CCD cameras. This manual off-axis guider allows you to guide from your primary telescope with the same unfiltered light detected by your camera’s sensor. Because you are guiding in front of your filter wheel, you will be able to see more stars.

The Officina Stellare 3" Off-Axis Guider comes with a Borg 7315 1.25" helical focuser installed at the guiding port. This non-rotating lightweight focuser has 50 micron index marks on the outside of the barrel, and offers 10mm of travel. It comes with the Borg 7317 1.25" eyepiece holder.

About This Product

OSBus is the new Advanced Telescope Controller from Officina Stellare. Completely designed and build from us, can remotely control every function on OS' Truss telescopes. It is provided with OS control software. You can manage fans, shutters, focusing, secondary mirror collimation and all functionalities installed into Officina Stellare telescopes.

About This Product

Add a focus motor to the secondary mirror of your Officina Stellare RiFAst, RiDK or RiLA 400 telescope. Control of the secondary mirror motor is achieved via the ATC-02 (sold separately). With the ATC-02 and the Secondary Mirror Focuser package, you can automatically find the optimum distance between the primary and secondary to achieve the best theoretical performance. This stage uses a linear stepper motor actuator with extremely high resolution (nm) for zero image shift focusing capabilities. Provided software is ASCOM compliant and can be used in conjunction with other programs to provide autofocus operations.

About This Product

With the SECMOT you can focusing using the secondary mirror, but with the SECTRI – Secondary Mirror Control Tripod – is possible both to focus and collimate using the secondary mirror. Tripod means you have not one, but three hi precision motors to move the secondary mirror. Needs OSBus to be operated.

About This Product

The Officina Stellare Collimation Kit offers users of their reflecting telescopes a simple yet precise way to keep optics collimated.

The Officina Stellare Collimation Kit includes:

• A custom, high powered 532 nm green holographic laser
• A precision-machined auto-centering laser adapter
• A hard case with instructions

About This Product

The Officina Stellare Deluxe Collimation Kit offers users of their reflecting telescopes a simple yet precise way to keep optics collimated.

The Officina Stellare Deluxe Collimation Kit includes:

• A custom, high powered 532 nm green holographic laser
• A precision-machined auto-centering laser adapter
• A Takahashi Collimating Telescope (TCE0100) & adapter
• A hard case with instructions

The collimation procedure is simple, fast and accurate. Simply put the assembled collimation kit in the back of the telescope and, using the sliding part of the Takahashi Collimation Scope, align the dot in the Tak scope with the dot present on the secondary mirror. Then, simply unscrew the light baffle of the primary mirror and, sliding the scope tube, focus on the 4 blades holding the secondary mirror. At this point you will see the blades and their reflections on the primary mirror. Using the collimation bolts on the back of the telescope, make adjustments until the four blades superimpose themselves perfectly on their reflection on the primary mirror. Once this is done, you are finished collimating! The whole operation takes about ten minutes.

About This Product

This high quality hard telescope case is designed to hold a 400 mm Officina Stellare RiLA, RiDK, or RiFA telescope. Made in Italy, the FLYCASE16 is super strong and beautifully finished. It has metal edge protectors and metal safety locks on the outside, and a soft lining on the inside to protect your telescope's finish.
