Product
Price
Quantity
10M-3083 - 10Micron 44 lbs. (20 kg) Counterweight (50 mm bore) for 3000HPS Mounts
About This Product
This 20 KG counterweight is exclusively designed for GM3000 mounts; a precise 50mm hole offers a smooth movement on the shaft and facilitates the balancing operations; the stainless steel guarantees no corrosion. For the best safe tightening, the counterweight is provided with a not protruding set screw.
$448.00 each
10M-3545 - 10Micron Clamping Plate Flange Adapter for 3000HPS Mounts (required for 3" and 4" saddles)
$282.00 each
10M-2085 - 10Micron Losmandy (3-inch) Dovetail Clamping Plate
About This Product
The Losmandy dovetail clamping plate 3” allow the use of standard Losmandy slide bar mounted optical tubes; this product is all CNC machined, black anodized aluminum. Two locking knobs ensure “top of safety” for your instruments. Lenght: 200mm.
$241.00 each
10M-2235 - 10Micron "Maxi" D-Series (3") Dovetail Clamping Plate, 350mm
About This Product
The “Maxi”-dovetail clamping plate 4″ XL is designed to accept 4” 10Micron dovetail slide bars, suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup. Lenght 350mm; 3 security locking knobs. Note for GM3000 & GM4000 users: Although it should be possible to accommodate this plate directly on the top of the GM3000 & GM4000 mount, due to the low profile of the clamping plates we strongly recommend using the special Flange Adapters 10M3545/10M4545 in order to operate the plate’s knobs with enough clearance.
$411.00 each
10M-2105 - 10Micron D-Series (3") Side-by-Side Bar and Saddles
About This Product
This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a standard 3” dovetail bar (Losmandy compatible) #10M2130; the clamping plates are two 3” Losmandy compatible (#10M2085). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: approx. 210, 245 and 281mm (8.3”, 9.6”, 11”). Note: – The GM1000 HPS Mount needs the #10M1105 Adapter in order to mantain the corret encoder’s position references – All the other mounts require a #10M2085 or #10M2185 3″ Losmandy clamping plate.
$565.00 each
10M-2135 - 10Micron “Maxi” (4-inch) Dovetail Clamping Plate
About This Product
The “Maxi”-dovetail clamping plate 4″ is designed to accept 4” 10Micron dovetail slide bars, suitable for heavier configurations. Advisable for example for optical tubes larger than 14” or for dual telescope setup. Lenght 200mm; 2 security locking knobs. Note for GM3000 & GM4000 users: Although it should be possible to accommodate this plate directly on the top of the GM3000 & GM4000 mount, due to the low profile of the clamping plates we strongly recommend using the special Flange Adapters 10M3545/10M4545 in order to operate the plate’s knobs with enough clearance.
$265.00 each
10M-2100 - 10Micron "Maxi" (4")/Losmandy (3") Side-by-Side Bar and Saddles
About This Product
This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a 4” dovetail bar 400mm long with special threaded holes (#10M2199); the clamping plates are 3” Losmandy compatible and 200mm long (#10M2085). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: appr. 210, 245 and 281mm (8.3”, 9.6”, 11”). Included in the set is a Maxi clamping plate (#10M2135) which fits directly on the GM2000 mounts and via the following adapters on the GM3000 and GM4000 mounts: #10M3545 | Flange adapter for clamping plates (GM3000) #10M4545 | Flange adapter for clamping plates (GM4000)
$837.00 each
10M-2100XL - 10Micron Lateral Double 4" Plate "Maxi-dual XL" - 400mm
About This Product
This special double plate is designed to allow a parallel mounting of two optical tubes on the 10Micron mounts. The bottom slide is a 4” dovetail bar 400mm long with special threaded holes (#10M2199); the clamping plates are 3” Losmandy compatible and 350mm long (#10M2185). All the components are CNC machined, black anodized aluminum. There are 3 different possible distances between the two clamps: appr. 210, 245 and 281mm (8.3”, 9.6”, 11”). Included in the set is a Maxi clamping plate (#10M2135) which fits directly on the GM2000 mounts and via the following adapters on the GM3000 and GM4000 mounts: #10M3545 | Flange adapter for clamping plates (GM3000) #10M4545 | Flange adapter for clamping plates (GM4000)
$959.00 each
10M-4550 - 10Micron 5" Wide Dovetail Clamping Plate
About This Product
This 5" dovetail clamping plate is a sturdy, black aluminum anodized, and machined clamp. It is provided with three safety locking screws and is designed to accommodate very heavy instruments. Designed for the 4000HPS mounts, it’s also suitable for the 3000HPS mounts.
$439.00 each
10M-4555 - 10Micron Giant 8" Wide Dovetail Clamping Plate
About This Product
The Giant Dovetail clamping plate 8” is an extra sturdy, black aluminum anodized machined clamp suitable for 8″ dovetail bars including those for Planewave OTA’s CDK 17, CDK 20 and CDK 24. Although it fits the medium-size the 2000HPS mounts, this clamping plate is specially recommended for very heavy optical configurations on the GM3000 and GM4000 mounts.
$560.00 each
